Full‑set NPK Fertilizer Granulation Production Line Rotary Drum Granulator Chemical Fertilizer Processing Machinery

Full‑set NPK Fertilizer Granulation Production Line Rotary Drum Granulator Chemical Fertilizer Processing Machinery

Brand Name:	HHITC
MOQ:	1
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	to be determined

Detail Information

Product Description

Detail Information

Place of Origin:

China

Materialofconstruction:

High-quality Steel

Supply Ability:

to be determined

Product Description

Complete NPK Compound Fertilizer Production Line

Production Line Overview

This complete NPK compound fertilizer production line is specially developed for producing granular compound fertilizer with adjustable nitrogen-phosphorus-potassium ratios. It covers the full-process workflow from automatic batching to finished-product packaging.

Finished NPK fertilizer granules feature uniform particle size, high mechanical strength, and good anti-caking performance, making them convenient for storage, transportation, and farm application. This turn-key solution is widely adopted by medium to large fertilizer factories for producing different-formula compound fertilizers.

Key Features

Flexible formula adjustment supporting various NPK proportion formulas for different crop demands
Two optional granulation technologies: wet drum granulation or dry double-roller extrusion granulation
High granulation rate, stable continuous running, low failure rate, and easy maintenance
Modular configuration with customizable whole-line layout according to customer workshop and site conditions
High automation level reducing manual operation with return material recycling system improving raw-material utilization
Finished round granules with high strength, resistant to breakage and anti-caking for long-term storage

Working Process

Raw material automatic batching
Crushing
Mixing homogenization
Granulation
Drying
Cooling
Rotary screening
Finished-product packaging

Unqualified oversized & fine powder returns back for re-granulation to realize material recycling.

Main Equipment Composition

Automatic Batching System: Accurately weighs nitrogen, phosphorus, potassium and filler raw materials
Material Crusher: Crushes agglomerated chemical raw materials into fine powder
Mixer: Fully blends multiple powder raw materials for even nutrient distribution
Granulator: Converts mixed powder into fertilizer granules (rotary drum / double-roller extrusion optional)
Rotary Dryer & Cooler: Reduces granule moisture and cools down hot fertilizer particles to prevent caking
Rotary Trommel Screen: Separates qualified granules from oversized and undersized return materials
Automatic Quantitative Packaging Machine: Weighs and seals finished NPK fertilizer bags

Application & Specifications

Application Scenarios: Compound fertilizer manufacturing plants, large-scale chemical fertilizer factories, agricultural fertilizer production projects.

Applicable Raw Materials: Urea, ammonium chloride, ammonium sulfate, monoammonium phosphate, diammonium phosphate, potassium chloride, potassium sulfate, bentonite and other NPK chemical filler raw materials.

Technical Specifications

Model	Capacity (t/h)	Total Installed Power (kw)	Suggested Workshop Area (㎡)
5t/h NPK Production Line	5	110	600
10t/h NPK Production Line	10	180	1000
15t/h NPK Production Line	15	260	1300
20t/h NPK Production Line	20	350	1600
